dji PHANTOM 2 VISION+ - Battery Life

©2014 DJI. All Rights Reserved.
show battery level. See below for details.
Battery Level Indicators will show the current battery level during charging and discharging. The
indicators are defined below.
: LED is on : LED blinks : LED is off
Discharging process
LED1
LED2
LED3
LED4
Current battery level
87.5%~100%
75%~87.5%
62.5%~75%
50%~62.5%
37.5%~50%
25%~37.5%
12.5%~25%
0%~12.5%
<0%
Battery life
When the battery is powered off, press and hold the Circular Power Button for 5 seconds to check battery life.
Battery Level Indicators will show light up and the Battery Power Indicators will blink for 10 seconds. All lights will
then turn off. For details, please see below.
Battery life
LED1
LED2
LED3
LED4
Current battery life
90%~100%
80%~90%
70%~80%
60%~70%
50%~60%
40%~50%
30%~40%
20%~30%
Less than 20%
When batter life reaches 0, it is no longer operational.
More battery information is available in the battery tab of the Phantom 2 Vision+ Assistant.
