Page #72 background imageLoading...
Page #72 background image
©2014 DJI. All Rights Reserved.
2 Specifications
Aircraft
Supported Battery
DJI 5200mAh Li-Po Battery
Weight (Battery & Propellers included)
1242g
Hovering Accuracy (Ready to Fly)
Vertical: 0.8m; Horizontal: 2.5m
Max Yaw Angular Velocity
200°/s
Max Tiltable Angle
3
Max Ascent / Descent Speed
Ascent: 6m/s; Descent: 3m/s
Max Flight Speed
15m/s (Not Recommended)
Diagonal motor-motor distance
350mm
Gimbal
Working Current
Static : 750mA; Dynamic : 900mA
Control Accuracy
±0.03°
Controllable Range
Pitch : -90°-0°
Maximum Angular Speed
Pitch : 90°/s
Camera
Operating Environment Temperature
0-40
Sensor Size
1/2.3
Effective Pixels
14 Megapixels
Resolution
4384×3288
HD Recording
1080p30 /1080i60
Recording FOV
110° / 85°
Remote Controller
Operating Frequency
5.728 GHz5.85 GHz
Communication Distance (open area)
CE Compliance: 400m; FCC Compliance: 800m
Receiver Sensitivity (1%PER)
-93dBm
Transmitting Power (EIRP)
CE Compliance: 25mW; FCC Compliance: 100mW
Working Current/Voltage
80 mA@6V
Battery
4 AA Batteries
Range Extender
Operating Frequency
2412MHz - 2462MHz
Communication Distance (open area)
500m - 700m
Transmitting Power
20dBm
Power Consumption
2W
