Linking Procedures

1. Power off the Remote Controller, power on the aircraft. You will see the link indicator blinking red.

2. Press the link button with a thin object and hold until the link indicator blinks yellow. Release the link

button.

3. Power on the Remote Controller. Link indicator will switch off, showing that a link has been successfully

established.

Link Indicator

Description

Next Operation

No signal received.

Switch on the Remote Controller or perform a link procedure.

Ready to link.

Switch on the Remote Controller.

5.7 Compliance Version Configuration

As power levels vary between regulators, the Phantom Remote Controller’s power output can be adjusted by

twisting the potentiometer knob (Figure 28) on the back of the Remote Controller using a flathead screwdriver. For

CE compliance, set the Remote Controller to CE with a full counterclockwise turn. For FCC compliance, set the

Remote Controller to FCC with a full clockwise turn. Be sure to follow relevant local regulations.

Compliance can be configured using the PHANTOM RC Assistant Software. Select CE compliance version in

Assistant Software to set it, or do the same with FCC compliance version.

FCCCE

Figure 28

(1) Turn the potentiometer knob gently to avoid damage.

(2) CE compliant devices have an effective communication range of 400 meters in open spaces

due to power limitations.

(3) FCC compliant devices have an effective range of 800 meters in open spaces.

(4) Watch your flight distance as the Phantom 2 Vision+ will enter Failsafe mode (auto-landing or

go home and land) if it flies beyond the relevant range limits.

(5) Always follow local laws and regulations.
