2 Starting/Stopping the Motors
2.1 Starting Motors
A Combination Stick Command (CSC) is used to start the motors instead of simply pushing the stick up. (Figure 50)
Push both sticks to their bottom corners to start the motors. Once the motors have spun up, release both sticks
simultaneously.
Figure 50
2.2 Stopping Motors
There are two methods to stop the motors.
Method 1: When the Phantom has landed, push the throttle down, then conduct CSC. Motors will stop immediately.
Release both sticks once motors stop.
①
②
Figure 51
Method 2: When the aircraft has landed, push the throttle down and hold. Motors will stop after 3 seconds.
Figure 52
Do not execute CSC during normal flight. This will stop the motors and cause the aircraft to drop without
control.
Conduct the CSC as neatly as you can. Release the sticks once motors start/stop.
