6 Flight Limits
All unmanned aerial vehicle (UAV) operators should abide by all regulations from such organizations as the ICAO
(International Civil Aviation Organization) and their own national airspace regulations. For safety reasons, the flight
limits function is enabled by default to help users use this product safely and legally. The flight limits function
includes height, distance limits and No Fly Zones.
In Ready to Fly mode, height, distance limits and No Fly Zones work together to manage flight. In Ready to Fly
(non-GPS) status, only height limits work and flights cannot go higher than 120m.
Default parameters in Assistant Software are compliant within the definitions of class G ruled by ICAO.
(Refer to Airspace Classification to get more details). As each country has its own rules, make sure to
configure these parameters to comply with these rules before flying.
6.1 Max Height & Radius Limits
Max Height & Radius limits flying height and distance. Configuration can be done in the Phantom 2 Vision+
Assistant (Figure 57). Once complete, your Phantom will fly in a restricted cylinder (Figure 58).
Max
Height
Max
Radius
Home Point
Height of
aircraft when
powered on
Figure 57 Figure 58
Ready to Fly
Limits
DJI VISION App
Rear LED flight indicator
Max Height
Flight height must be under the set
height.
Warning: Height limit
reached.
None.
Max Radius
Flight distance must be within the
max radius.
Warning: Distance limit
reached.
Rapid red flashing
when close to the max radius limit.
