©2014 DJI. All Rights Reserved.
2 Camera Page
[1]
[2]
[3]
[6]
[4]
[5]
[8]
[7]
[9]
[11]
[12]
[13]
[14]
[10]
Figure 62
[1]Return [2] Camera Pitch Control [3] Flight Attitude and Radar Function [4] Flight Parameters [5] Wi-Fi Signal
Intensity [6] Flight Battery Level [7] Aircraft GPS Status [8] Micro-SD Card Status [9] Range Extender Battery Level
[10] Remaining Shots [11] Shutter Button [12] Video Recording Button [13] Camera Settings [14] Hide or Show Flight
Parameters
[1] Return
- Return to the preview page
[2] Camera Pitch Control
- Pitch Control switch is white tap once to highlight it and enter Accelerometer Sensor Mode. Tap
again to return to normal.
Normal Mode
Tap up arrow to pitch camera upwards and down arrow to pitch downwards. Green slider indicates
current camera pitch.
Gimbal pitch control (Normal Mode)
Gimbal pitch movement
Figure 63
Figure 64
