Figure 68

Tap flight attitude icon to turn on the radar function. Home in the center of the radar and the red icon indicates

the Phantom 2 Vision+’s current heading, direction, and approximate distance from home. Tap flight attitude

icon again to disable the radar.

Home

Point

Aircraft

Position

Mobile Device

Position

Distance

Figure 69 Figure 70

(1) By default, the center of the radar indicates the home point recorded by the Phantom 2 Vision+.

Tap the center of the radar to switch the center to your mobile device's current location.

(2) If your mobile device contains a compass, the top portion of the Radar is the direction you are

pointing. If not, the radar will be oriented due north.

(3) Distance units are metric in Figure 69 and Figure 70. Users can switch the unit to imperial in the

settings page.

[4] Flight Parameters

Distance: Horizontal distance from home point.

Altitude: Vertical distance from home point.

Speed: Horizontal flying speed.

Distance value will show as N/A if the Phantom 2 Vision+ is not in “Ready to Fly” mode.

[5] Wi-Fi Signal Intensity

Indicates camera is connected to your mobile device and Wi-Fi is working normally.

The connection between the camera and mobile device may fail if Wi-Fi signal strength is low. Refer to <

Phantom 2 Vision+ CONNECTION BROKEN> for more information.

[6] Flight Battery Level

Show current flight battery level. When battery level is low and the battery icon turns red it is recommended to fly
