©2014 DJI. All Rights Reserved.
Appendix
1 Rear LED Flight Indicator Status
Rear LED Flight Indicators
Normal status
(Red, Green, Yellow flashes in turn)
Power On Self-Test
(Green, Yellow flashes in turn)
Warming Up
(Slow Green flashes)
Ready to Fly
(Slow Yellow flashes)
Ready to Fly (non-GPS)
Rear LED Flight Indicators
Abnormal status
(Quick Yellow flashes)
Remote Controller Signal Lost
(Slow Red flashes)
Low Battery Level Warning
(Quick Red flashes)
Critical Low Battery Level Warning
(Three Red flashes off and on)
Not Stationary or Sensor Bias is too big
(Solid red)
Error*
(Red, Yellow flashes in turn)
Compass Needs Calibration
*You can investigate the error by connecting the Phantom 2 Vision+ to the Phantom 2 Vision+’s Assistant
Software.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji PHANTOM 2 VISION+ and is the answer not in the manual?

dji PHANTOM 2 VISION+ Specifications

General IconGeneral
Camera14 MP
Gimbal3-axis
Flight Time25 minutes
Battery5200 mAh LiPo 3S
GPSYes
Diagonal Size350 mm
Max Ascent Speed6 m/s
Max Descent Speed2 m/s
Max Speed15 m/s
Return to HomeYes
Video Resolution1080p
Control Range700 meters
Weight1242 g
Operating Temperature-10°C to 50°C
Live ViewYes
