Digital Monitoring Products XR500 Series Installation Guide
2
INTRODUCTION
Panel Features
2.1 Description
The DMP XR500 Series panel is a versatile 12 Vdc, combined access control, burglary, and re communicator panel
with battery backup. The XR500 Series provides eight on-board burglary zones and two on-board 12 Vdc Class B
powered zones. The powered zones have a reset capability to provide for 2-wire smoke detectors, relays, or other
latching devices. The XR500 Series can communicate to DMP SCS-1R or SCS-VR Receivers using digital dialer, cellular,
network, or Contact ID communication.
2.2 Zone Expansion
Up to 574 additional zones are available on the XR500 Series using DMP LCD keypad remote zone capability and zone
expansion modules. The panel keypad data bus supports up to sixteen supervised device addresses with each address
supporting up to four programmable expansion zones.
Up to 500 zones are available using the on board LX-Bus, Model 461 Interface Adaptor with 481, 462N, 462P, 463C,
464-263C and 464-263H Interface Cards, and any combination of single, four, eight, or 16-zone expansion modules
and single-zone LX-Bus™ detectors.
Note: Do not use shielded wire for LX-Bus or Keypad Bus circuits.
2.3 Output Expansion
In addition to the two SPDT relays and four programmable open collector outputs on the XR500 Series, you can also
connect up to 25 programmable Model 716 Output Expansion Modules to each LX-Bus. These modules can provide an
additional 500 programmable SPDT relays.
The XR500 Series provides 100 Output Schedules for programming the 716 to perform a variety of annunciation and
control functions. Also assign the 716 outputs to any panel Output Options such as Fire Alarm, Communication Fail,
or Phone Trouble Outputs. Refer to the 716 Installation Guide (LT-0183).
The LX-Bus™ also supports the Model 717 Graphic Annunciator Module. Each 717 module supplies 20 switched ground
outputs that follow the state of their assigned zones.
Note: The 717 supports the rst eight Keypad Bus addresses. To follow Keypad Bus addresses nine through 16, install
multiple 716 modules. Refer to the 717 Installation Guide (LT-0235) and 716 Installation Guide (LT-0183).
2.4 Central Station Communication
You can program the XR500 Series panel for reporting to DMP SCS-1R or SCS-VR Receivers using digital dialer, cellular,
network, or Contact ID communication. The XR500 Series connects at the premises to a standard RJ31X or RJ38X
telephone jack. Use the DMP 893A Dual Phone Line Module when connecting the XR500 Series panel to two separate
phone lines in re or burglary applications.
2.5 Encrypted Communications (XR500N/XR500E only)
An XR500E panel communicates using AES encryption. If you currently have an XR500N panel installed, you may
contact DMP Customer Service with the panel serial number. The serial number(s) should be sent in writing via
e-mail or fax. A separate feature key is sent for each panel to activate encrypted communications using the Feature
Upgrade process. Encrypted communication cannot be enabled on a standard XR500 panel. For more information on
the Feature Upgrade process see the XR500 Series Programming Guide (LT-0679).
2.6 Caution Notes
Throughout this guide you will see caution notes containing information you need to know when installing the panel.
These cautions are indicated with a yield sign. Whenever you see a caution note, make sure you completely read
and understand its information. Failing to follow the caution note can cause damage to the equipment or improper
operation of one or more components in the system. See the example shown below.
Always ground the panel before applying power to any devices: The XR500 Series must be properly
grounded before connecting any devices or applying power to the panel. Proper grounding protects against
Electrostatic Discharge (ESD) that can damage system components.
2.7 Compliance Instructions
For applications that must conform to a local authorities installation standard or a National Recognized Testing
Laboratory certicated system, please see the Wiring Diagrams for Notication Appliances and the Listed Compliance
Specications section near the end of this guide for additional instructions.
