Digital Monitoring Products XR500 Series Installation Guide
30
COMPLIANCE
Police Station Connected and Local Burglar Alarm Units
ANSI/UL 609
28.1 Mercantile
For Mercantile and Police Station Connect operation the Model XR500 Series must be mounted in an Attack Resistant
Housing, (DMP Model 350A or 350H).
28.2 Entry Delay
The maximum entry delay used must not be more than 60 seconds when using the Model 350A or 350H housing.
28.3 Exit Delay
The maximum exit delay used must not be more than 60 seconds.
28.4 Mercantile Safe and Vault
When the DMP Model 350A or 350H Attack housing is used, the XR500 Series provides operation as a mercantile
safe and vault alarm. Bell Supervision and wiring must be in accordance with ANSI/UL 681. When the XR500 Series
is mounted outside the safe or vault, tamper protection and the Sentrol Model 5402 or Potter EVD listed vibration
detectors should be used.
28.5 Bell
A local audible signal appliance must be used such as Ademco AB12M bell and bell housing.
In a mercantile burglar alarm system, a mercantile alarm sounding device located within a building but outside the
protected area, is acceptable, provided it is rated for outside service and alarm conditions are transmitted to:
a) The dispatch location of the law enforcement agency having jurisdiction over the protected property or
b) A central station or residential monitoring station complying with the Standard for Central Station Alarm
Services, UL 827.
In a mercantile burglar alarm system, an alarm sounding device located within the area of greatest protection, or
outside the area of greatest protection but within an area protected by an alarm system and that shares a common
control unit with the system installed in the area of greatest protection, is acceptable provided it is rated for inside
service and alarm conditions are transmitted to:
a) The dispatch location of the law enforcement agency having jurisdiction over the protected property or
b) A central station or residential monitoring station complying with the Standard for Central Station Alarm
Services, UL 827.
An inside sounding device shall be mounted at least 10 feet (3.05 m) above the oor or at the surface of the ceiling.
When there is xed construction within the area that could provide access for an intruder, the alarm sounding
device shall also be mounted at least 4 feet (1.2 m), as measured horizontally, away from the edges of the xed
construction or at least 10 feet (3.05 m) above it so as to minimize access by an intruder.
28.6 Bank Safe and Vault (XR500N/XR500E only)
The Bank Safe and Vault option must be programmed as YES. The 72 hour battery standby must be provided. A
Rothenbuhler Model 5110 High Security Bell must be used.
28.7 Wireless Audible Annunciation Option
The Wireless Audible option must be selected as ANY for commercial applications.
