XR500 Series Installation Guide Digital Monitoring Products
41
WIRING DIAGRAMS
36.3 866 Class B Style W Multiple Notication Appliance Circuit
AC
1234 5678 10 11 12 13 14 15 16 17 18 199202122232425262728
+B BELL GND SMK GNDRED YEL GRN BLKZ1Z2Z3Z4Z5Z6Z7Z8 Z9+ Z9- Z10+ Z10-AC -B GND GND GNDGND
K6 K7
Output 1
Output 2
J3
Phone Line
J10
J22
LX-Bus
Battery
Start
J21
RS-232
Power LED
J8
PROG
J4
Tamper
Out2
J11
3
4
5
6
J2
J1
Ethernet
XR500 Series Command
Processor™ Panel
PANEL
MAIN BACKUP
P3
J4
J5
K1
J1
F2
F1
J2
K2
P10
DS1
Buzzer
+
–
Model 310
1K EOL
505-12 Power
Supply
J6
+ DC -
AC
Trouble
Batt
Trouble
J4
J3J2
Green
LED
AC
AC
+ BAT -
Red
LED
DC
12 VDC @ 5 Amps
Battery
Start
The Auxiliary Power Supply and Notification Circuit
Module trouble contact zone must be programmed
as a Supervisory Type zone and must be selected
for display in the keypad status list.
Auxiliary Power Supply must be regulated, power
limited, and listed for Fire Protective Signaling
Service. Power Supplies must have battery backup.
Note: If an auxiliary power supply is not used,
terminals 3 and 4 can be jumpered together to
supply Bell Power from the panel.
Polarized Notification
Appliances
1 AUX PWR
2 GND
3 Alarm In
4 Bell PWR In
5 Bell Out +
6 Bell Out -
7 Bell Trouble
8 Bell Trouble
Normal/Silence Switch
Model 308
10K EOL
DMP Model 866
45mA @ 12 VDC
The Model 866
Notification Appliance
Circuit Module in
alarm draws up to
31mA through
Terminal 3 Alarm
Input and 45mA from
Terminal 1 Aux Power
Input.
SM-12/24 Module
Sync module required when
using multiple notification
appliances
When using a separate power supply, the
maximum current is 3 Amps.
See the Notification Appliance
section for a list of appliances.
The maximum voltage drop
between the panel Bell Output and
the Model 308 is 1 VDC when a
separate power supply is not used.
The Bell Output
programming for Fire
type zones must be set
to Steady.
Regulated
12 VDC
J6 Interface
Card
Expansion
Connector
J23
R
L
X
J12
75VA
50VA
To Next Page
