Digital Monitoring Products XR500 Series Installation Guide
54
WIRING DIAGRAMS
36.16 Rothenbuhler 5110 High Security Bell Wiring.
J6
Interface
Card
Expansion
Connector
XR500 Series
Command Processor™
Panel
K3
J2 Output Header
All outputs must be located
within the same room as
the control panel.
AC
12345678 10 11 12 13 14 15 16 17 18 199202122 23 24 25 26 27 28
+B BELL GND SMK GNDRED YEL GRN BLK Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8 Z9+ Z9– Z10+Z10–AC –B GND GND GNDGND
K6 K7
J3
J10
J22
Battery Start
J23
J21
RS-232
J4
Tamper
J16
Reset
J11
J2
J1
S = Supervised Circuit
Green LED
Red LED
Silence
BLO
BLI
Test
Common
+ 12 VDC
Rothenbuhler 5110
High Security Bell
SS
10K EOL
DMP Model 308
10K EOL
DMP Model
308
Output 1 Common
Output 2 Common
Output 1 N/C Output 2 N/C
Model 431 Output
Harness
R
L
X
J12
75VA
50VA
