Digital Monitoring Products XR500 Series Installation Guide
36
COMPLIANCE
New York City (FDNY) Specications
34.1 Introduction
The programming specications contained in section 34.2 or 34.3 must be completed when installing the XR500
Series panel for New York City (FDNY) re alarm installations for IP communication applications. Refer to the FDNY
Certicate of Approval #6123 or #6145 for the complete conditions of approval.
Note: Fire alarm installations that use two digital dialer telephone lines do not need to comply with these two
sections.
34.2 Network and Cellular Communication, Primary and Secondary
When installed as a central station Internet (Network) communicator or slave transmitter both primary
and secondary channels of communication shall be required and shall meet the conditions below. Network
communication shall be used as primary channel of communication with Central Station and a 463C Cellular
Communicator shall be used as the secondary channel of communication or in reverse order: 463C Cellular
Communicator as primary and Network connection as the secondary channel.
Path 1 Type NET Primary and Path 2 Type CELL Backup Programming
Path 1 Programming Path 2 Programming
Comm Type = NET Comm Type = CELL
Path Type = Primary Path Type = Backup
Checkin Min = 5 Checkin Min = 5
Failtime Min = 5 Failtime Min = 5
Test Rpt = Yes Test Rpt = Yes
Test Freq = 1 Dy Test Freq = 1 Dy
Send Comm Trbl = Yes Send Comm Trbl = Yes
Comm Path Trbl = Yes (Status List Programming)
Path 1 Type CELL Primary and Path 2 Type NET Backup Programming
Path 1 Programming Path 2 Programming
Comm Type = CELL Comm Type = NET
Path Type = Primary Path Type = Backup
Checkin Min = 5 Checkin Min = 5
Failtime Min = 5 Failtime Min = 5
Test Rpt = Yes Test Rpt = Yes
Test Freq = 1 Dy Test Freq = 1 Dy
Send Comm Trbl = Yes Send Comm Trbl = Yes
Comm Path Trbl = Yes (Status List Programming)
34.3 Digital Dialer Primary and Network Secondary Communication
When used with a central oce communicator or a transmitter, the installation and operation of the equipment and
devices shall comply with 3RCNY 17-01. The installation shall employ the digital dialer as the primary communicator
(using telephone line) with network IP communication as backup or secondary means of communication. It shall
have the capability of transmitting separate and distinct signals to indicate manual pull station alarm, automatic
detection alarm, sprinkler waterow alarm, supervisory signal indications and trouble indications.
34.3.1 Communication Programming
For digital dialer communication with supervised network backup, program the following:
PRIMARY COMM TYPE = DD
FIRST PHONE NUMBER = Central Station Receiver Phone Number
BACKUP COMM TYPE = NET
RECEIVER
ALARMS = YES
34.4 Wiring
All wiring must be in accordance with NEC, ANSI, and NFPA 70. All network cabling must be installed in accordance
with NFPA 70 for communication circuits.
34.5 Additional Requirements
Program and install the equipment to comply with NFPA basic re requirements. Refer to the Universal Fire Alarm
Specications and ANSI/UL 864 NFPA 72 Specications in this document.
