DMP Electronics XR500N SERIES User Manual

Digital Monitoring Products XR500 Series Installation Guide
42
WIRING DIAGRAMS
36.4 866 Class B Style W Dual Notication Appliance Circuits
MINUS 2MINUS 1+OUT 1 +IN 1 +IN 2-AUD+AUD +OUT 2
AC
1234 5678 10 11 12 13 14 15 16 17 18 199202122232425262728
+B BELL GND SMK GNDRED YEL GRN BLKZ1Z2Z3Z4Z5Z6Z7Z8 Z9+ Z9- Z10+ Z10-AC -B GND GND GNDGND
K6 K7
Output 1
Output 2
J3
Phone Line
J10
J22
LX-Bus
Battery
Start
J21
RS-232
Power LED
J8
PROG
J4
Tamper
Out2
J11
3
4
5
6
J2
J1
Ethernet
XR500 Series Command
Processor™ Panel
Model 308
10K EOL
PANEL
MAIN BACKUP
P3
J4
J5
K1
J1
F2
F1
J2
K2
P10
DS1
Buzzer
+
–
Normal
S1
J2
CR6
CR5
Bell
Silence
GND
FAULT
TRBL
J1
1
2
3
4
5
6
7
8
9
10
11
505-12 Power
Supply
J6
+ DC -
AC
Trouble
Batt
Trouble
J4
J3J2
Green
LED
AC
AC
+ BAT -
Red
LED
DC
12 VDC @ 5 Amps
Battery
Start
The Auxiliary Power Supply and Notification
Circuit Module trouble contact zone must be
programmed as a Supervisory Type zone and
must be selected for display in the keypad
status list.
Auxiliary Power Supply must be regulated, power
limited, and listed for Fire Protective Signaling
Service. Power Supplies must have battery backup.
Note: If an auxiliary power supply is not used,
terminals 3 and 4 can be jumpered together to
supply Bell Power from the panel.
Bell Out A +
Bell Trouble
Bell Trouble
Bell Out A -
Bell Out B +
Bell Out B -
AUX PWR
GND
Alarm In
Bell PWR In +
Bell PWR In -
DMP Model 865
26mA @ 12 VDC
The Model 865
Notification Appliance
Circuit Module in
alarm draws up to
59mA through its
Terminal 3 Alarm
Input and 26mA from
the Terminal 1
Aux Power Input.
Polarized Notification Appliances
Model 310
1K EOL
DSM-12/24 Module
Model 308
10K EOL
Sync module required when
using multiple notification
appliances
When using a separate
power supply, the
maximum current is 3
Amps.
See the Notification Appliance section for a list of appliances.
The maximum voltage drop
between the panel Bell Output and
the Model 308 is 1 VDC when a
separate power supply is not used.
The Bell Output
programming for Fire
type zones must be set
to Steady.
Regulated
12 VDC
J6 Interface
Card
Expansion
Connector
J23
R
L
X
J12
75VA
50VA
