XR500 Series Installation Guide Digital Monitoring Products
5
INTRODUCTION
3.4 Accessory Devices (continued)
DMP Two-Way Wireless Devices (continued)
1131 Recessed Contact* Provides a recessed contact option for door or window applications.
1135 Wireless Siren* Provides a wireless siren.
1137 Wireless LED Emergency
Light
Provides path lighting in the event of an alarm or trouble such as Burglary Alarm Output
or can be activated simultaneously by the panel via the Trip with Panel Bell feature.
1139 Bill Trap* Provides a silent alarm option for retail and banking cash drawers.
1141 Wall Button* One button wall mounted wireless transmitter.
1142BC Two-button Hold-up
Belt Clip Transmitter
Provides two-button hold-up operation with a belt clip.
1142 Two-button Hold-up
Transmitter
Provides permanently mounted under-the-counter two-button hold-up operation.
1144-4 (Four-Button)*
1144-2 (Two-Button)*
1144-1 (One-Button)*
Key Fob transmitters designed to clip onto a key ring or lanyard.
1164NS Wireless Commercial
Smoke
Battery powered, wireless, low prole, photoelectric smoke detector.
1165 Commercial Smoke
Detector
Commercial smoke detector.
1183-135F Heat Detector Fixed temperature heat detector.
1183-135R Heat Detector Fixed temperature and rate-of-rise heat detector.
1184 Carbon Monoxide
Detector
Carbon monoxide detector.
Indicating and Initiating Devices
860 Relay Module* Provides dry relay contacts that are programmable and controlled from the DMP panel
annunciator outputs. Includes one Form C (SPDT) relay rated 1 Amp @ 30 Vdc. Sockets
are provided to allow the addition of three Model 305 plug-in relays.
865 Supervised Style W or X
Notication Circuit Module
Provides supervised alarm current when using the XR500 Series panel bell output
and up to 5 Amps at 12 or 24 Vdc when using a listed auxiliary power supply. The 865
can supervise 2-wire or 4-wire style circuits for opens and shorts with individual LED
annunciation.
866 Style W Notication Circuit
Module
Provides supervised alarm current using the XR500 Series panel bell output and up to 5
Amps at 12 or 24 Vdc when using a listed auxiliary power supply. The 866 can supervise
2-wire Style W circuits for opens and shorts.
867 Style W LX-Bus Notication
Circuit Module
Provides supervised alarm current using the XR500 Series panel bell output and up to 5
Amps at 12 or 24 Vdc when using a listed auxiliary power supply. The 867 connects to the
XR500 Series panel LX-Bus™ and provides one 2-wire Style W notication circuit for open
and short conditions. Individual Bell Relay addresses Bell Ring styles.
869 Dual Class A Style D
Initiating Module
Provides two Class A, Style D, 4-wire initiating zones for connecting waterow switches
and other non-powered re and burglary devices.
Accessory Modules and Keypads
893A Dual Phone Line Module Allows you to supervise two standard phone lines connected to an XR500 Series panel.
The 893A module monitors the main and backup phone lines for a sustained voltage drop
and alerts users when the phone line is bad.
LCD keypads Allows you to control the panel from various remote locations. Connect up to sixteen
supervised Model 630F Remote Fire Command Center, Model 7060, 7063, 7070, 7073,
7160, 7163, 7170, 7173 Thinline™ keypads, 7060A, 7063A, 7070A, 7073A Aqualite™
keypads, 7760 Clear Touch™ keypad, or 7872, 7873 Graphic Touchscreen keypads to the
keypad bus using terminals 7, 8, 9, and 10.
9000 Series Wireless keypads Allows you to control the panel from various remote locations. Connect up to four
9060/9063 Wireless Keypads.
9800 Series Wireless
Graphic
Touchscreen keypads
Allows you to control the panel from various remote locations. Connect up to four
keypads. 9862 Wireless Keypads.
Addressable Smoke Detectors
2W-BLX, 2WT-BLX Single-zone, addressable conventional smoke, smoke/heat detectors that connect to the
LX-Bus. Includes drift compensation.
* Security Device Only: This device has not been investigated and shall not be used in listed installations.
