XR500 Series Installation Guide Digital Monitoring Products
33
COMPLIANCE
Control Units for Fire-Protective Signaling Systems
ANSI/UL 864, NFPA 72
31.1 Power Supply
For listed Commercial Fire installations, the 50 VA Plug-in transformer cannot be used.
The total combined current from Terminals 7, 11, 25, and 27 cannot exceed 1.2 Amps.
31.2 Zone Restoral Reports
The Restoral Reports option must be selected as YES or Disarm.
31.3 Power Fail Delay
The Power Fail Delay option must be selected as required by the service of the panel. For Central Station service:
6-12, for Remote Station service: 12-15.
31.4 Sprinkler Supervisory
Any zone used for sprinkler supervisory must be programmed with “SPRINKLR XXX” as the zone name. The last three
characters in the zone name may be assigned a number to identify the zone. The Model 893A Dual Phone Line Module
must be used on all sprinkler supervisory systems.
31.5 DACT Systems
A DACT system may be congured as one of the following:
Path 1 Type DD Primary and Path 2 Type DD Backup
Path 1 Type DD Primary and Path 2 Type CELL Backup
Path 1 Type DD Primary and Path 2 Type NET Backup
Path 1 Type DD Primary and Path 2 Type DD Backup
Use two telephone lines and the Model 893A Dual Phone Line Module to provide two phone line connections to the
system. Two dierent telephone numbers must be programmed for digital communication. Do not connect to ground
start or party lines.
Path 1 Programming Path 2 Programming
Comm Type = DD Comm Type = DD
Path Type = Primary Path Type = Backup
Test Rpt = Yes Test Rpt = Yes
Test Freq = 1 Dy Test Freq = 1 Dy
893A = Yes
Path 1 Type DD Primary and Path 2 Type CELL Backup
Path 1 Programming Path 2 Programming
Comm Type = DD Comm Type = CELL
Path Type = Primary Path Type = Backup
Test Rpt = Yes Test Rpt = Yes
Test Freq = 1 Dy Test Freq = 1 Dy
Receiver IP Address
First GPRS APN
Path 1 Type DD Primary and Path 2 Type NET Backup
Path 1 Programming Path 2 Programming
Comm Type = DD Comm Type = NET
Path Type = Primary Path Type = Backup
Test Rpt = Yes Test Rpt = Yes
Test Freq = 1 Dy Test Freq = 1 Dy
Receiver IP Address
31.6 Local Protective Signaling Systems
The DMP Model 865, 866, or 867 Notication Circuit Module must be used on the bell circuit for detection of shorts
and grounds. Any burglary or other o premises communication must be done with the Model 893A Dual Phone Line
Module. For local commercial re installations, the 893A is required.
