INTRODUCTION
3.3 Lightning Protection
Metal Oxide Varistors and Transient Voltage Suppressors help protect against voltage surges on XR500 Series input
and output circuits. Additional surge protection is available by installing the DMP 370 or 370RJ Lightning Suppressors.
3.4 Accessory Devices
Interface Adaptor and Interface Cards
461 Interface Adaptor Card Allows you to connect two or more expansion interface cards to the XR500 Series
panel. The 461 is an expansion mother board that plugs into the panel J6 Interface
Connector and is required when using two or more Interface Cards. Use combinations
of Interface Cards for expanding zones, network interfacing, local printing, and
connecting wireless devices.
462P Printer Interface Card Allows you to connect the XR500 Series to any compatible serial printer providing the
user with real-time event recording. The 462P also provides an LX-Bus™ for connecting
zone and output expansion modules.
464-263C/464-263H Cellular
Communicator Card
Provides a fully supervised alarm communication path over the CDMA network or HSPA
+ network for XR500 Series panels. The 464-263C or 464-263H also provides an LX-Bus™
for connecting zone and output expansion modules to the panel.
481 Expansion Interface Card Provides one LX-Bus for connecting up to 100 zone and output expansion modules.
Expansion Modules
710 Bus Splitter/Repeater Allows you to increase keypad or LX-Bus™ wiring distance to 2500 feet.
711 Single Point Zone Expanders Provides one Class B zone for connecting burglary devices.
714, 714-8, 714-16 Zone
Expanders
Provides Class B zones for connecting burglary and non-powered re devices.
712-8 Zone Expander Provides Class B zones for connecting burglary devices.
715, 715-8, 715-16 Zone
Expanders
Provides 12 Vdc Class B powered zones for connecting smoke detectors, glassbreak
detectors, and other 2- or 4-wire devices.
716 Output Expander Provides four Form C relays (SPDT) and four switched grounds (open collector) for use
in a variety of remote annunciation and control applications for use on the LX-Bus only.
717 Graphic Annunciator Module Provides 20 zone following annunciator outputs (open collector) for use in a variety of
remote annunciation and control applications for use on the LX-Bus only.
734, 734N, 734N-WiFi Wiegand
Interface Modules*
Provides system codeless entry, and arming and disarming using access control readers.
DMP Two-Way Wireless Devices
1100X/1100XH Receiver Supports up to 500 devices in residential or commercial wireless operation.
1100R Repeater Provides additional range for wireless devices.
1101 Universal Transmitter Provides both internal and external contacts that may be used at the same time to
yield two individual reporting zones from one wireless transmitter.
1102 Universal Transmitter Provides an external contact.
1103 Universal Transmitter Provides both internal and external contacts that may be used at the same time to
yield two individual reporting zones from one wireless transmitter. Requires EOL
resistor for external contact. Provides Disarm/Disable functionality.
1106 Universal Transmitter Provides both internal and external contacts that may be used at the same time to
yield two individual reporting zones from one wireless transmitter.
1107 Micro Window Transmitter* Provides a wireless window transmitter.
1114 Four-Zone Expander* Provides four wireless zones.
1115 Wireless Temperature
Sensor and Flood Detector*
Temperature and ood detector with an internal temperature sensor. Can be paired
with 470PB or T280R remote sensors.
1116 Relay Output* Provides one Form C relay.
1117 LED Annunciator* Provides a visual system status indicator.
1118 Remote Indicator Light* Provides a visual indication of a Panic situation.
1119 Door Sounder* Provides a battery powered sounder.
1121 PIR Motion Detector* Provides motion detection with pet immunity.
1126R PIR Motion Detector* Ceiling mount motion detector with panel programmable sensitivity and Disarm/Disable
functionality.
1127C/1127W PIR Motion
Detector
Wall mount motion detector with panel programmable sensitivity and Disarm/Disable
functionality.
1129 Glassbreak Detector* Detects the shattering of framed glass mounted in an outside wall and provides full-
pattern coverage and false-alarm immunity.
