XR500 Series Installation Guide Digital Monitoring Products
27
COMPLIANCE
Holdup Alarm Units
ANSI/UL 636
25.1 ANSI/UL 1610 Required
The programming and installation specications contained in this section must be completed in addition to
ANSI/UL 1610 Specications when installing a Model 1142 with a Model XR500 Series panel.
25.2 1100X/1100XH Wireless Receiver
The Model 1100X/1100XH Wireless Receiver in conjunction with the Model 1142 Holdup Alarm Transmitter must be
installed in the system.
25.3 Wireless Supervision Time
The Zone Information Supervision Time must be a maximum of 240 minutes.
25.4 LED Display
The LED Operation option display must be set to NO when using a Model 1142 Holdup Alarm Transmitter.
25.5 Jamming Detection
The Detect Wireless Jamming option must be set to YES.
25.6 Local Alarm
The Bell Action for a PN (Panic) type zone must be programmed as N (None).
25.7 Message to Transmit
The Armed Open and Armed Short messages for a PN (Panic) type zone must be programmed to A (Alarm).
25.8 Wireless Audible Annunciation Option
The Wireless Audible option must be selected as ANY for commercial applications.
Digital Burglar Alarm Communicator System Units
ANSI/UL 1635
26.1 System Trouble Display
The Status List Display must include at least one keypad that displays system monitor troubles.
26.2 Digital Dialer Telephone Number
Both programmed telephone numbers must begin with a P.
26.3 Test Time
The Test Time option must be programmed so that the XR500 Series sends a report once every 24 hours.
26.4 Closing Wait
The Closing Wait option must be programmed YES.
Police Station Connected and Local Burglar Alarm Units
ANSI/UL 365
27.1 System Trouble Display
The Status List Display must include at least one keypad that displays system monitor troubles.
27.2 Entry Delay
The maximum entry delay used must not be more than 60 seconds when using Model 350A or 350H Attack housing.
27.3 Exit Delay
The maximum exit delay used must not be more than 60 seconds.
