DMP Electronics XR500N SERIES User Manual

Digital Monitoring Products XR500 Series Installation Guide
12
INSTALLATION
Standby Battery Power Calculations Standby Current Alarm Current
736P POPIT Interface Module
Radionics Popex, POPITs, OctoPOPITs
Qty_______
Qty ______
x
x
25mA
___mA
______
______
Qty ______
Qty ______
x
x
25mA
___mA
______
______
738A Ademco Wireless Interface Module Qty ______ x 75mA ______ Qty ______ x 75mA ______
710 Bus Splitter/Repeater Module Qty ______ x 32mA ______ Qty ______ x 32mA ______
711 Zone Expansion Module
Active Zone (EOL Installed)
Qty ______
Qty ______
x
x
11mA
1.6mA
______
______
Qty ______
Qty ______
x
x
11mA
2mA*
______
______
714 Zone Expansion Module
Active Zones (EOL Installed)
Qty ______
Qty ______
x
x
7mA
1.6mA
______
______
Qty ______
Qty ______
x
x
7mA
2mA*
______
______
712-8 Zone Expansion Module
Active Zones (EOL Installed)
Qty ______
Qty ______
x
x
17mA
1.6mA
______
______
Qty ______
Qty ______
x
x
17mA
2mA*
______
______
714-8, 714-16 Zone Expansion Module
Active Zones (EOL Installed)
Qty ______
Qty ______
x
x
20mA
1.6mA
______
______
Qty ______
Qty ______
x
x
20mA
2mA*
______
______
715 Zone Expansion Module
Active Zones (EOL Installed)
2-Wire Smokes
Qty ______
Qty ______
Qty ______
x
x
x
7mA
4mA
.1mA
______
______
______
Qty ______
Qty ______
Qty ______
x
x
x
7mA
30mA*
.1mA
______
______
______
715-8, 715-16 Zone Expansion Modules
Active Zones (EOL Installed)
2-Wire Smokes
Qty ______
Qty ______
Qty ______
x
x
x
20mA
4mA
.1mA
______
______
______
Qty ______
Qty ______
Qty ______
x
x
x
20mA
30mA*
.1mA
______
______
______
716 Output Expansion Module
Active Form C Relays
Qty ______ x 13mA ______ Qty ______
Qty ______
x
x
13mA
12mA
______
______
717 Graphic Annunciator Module
Annunciator Outputs
Qty ______ x 10mA ______ Qty ______
Qty ______
x
x
10mA
1mA
______
______
521LX, 521LXT Smoke Detectors Qty ______ x 8.8mA ______ Qty ______ x 28mA* ______
2W-BLX, 2WT-BLX Smoke Detectors Qty ______ x 11mA ______ Qty ______ x 31mA* ______
COSMOD2W Module
COSMO-2W Smoke and CO Detectors
Qty ______
Qty ______
x
x
45mA
1mA
______
______
Qty ______
Qty ______
x
x
174mA*#
50mA*#
______
______
572 Indicator LED Qty ______ x 20mA ______ Qty ______ x 20mA ______
Aux. Powered Devices on Terminals 7 and 11
Other than Keypads and LX-Bus Modules
______mA ______mA
Sub-Totals this page only Sub-Total Standby ______ mA Sub-Total Alarm ______mA
Sub-Totals from previous page Sub-Total Standby ______ mA Sub-Total Alarm ______mA
*Based on 10% of active zones in alarm Total Standby ______ mA Total Alarm ______mA
# For systems that are not central station monitored, multiply alarm current by 12.
Total Standby ______ mA x number of Standby Hours needed
Total Alarm
______ =
______ mA
Total
_______ mA-hours
+ _______ mA-hours
_______ mA-hours
X .001
= _______ Amp-hrs Required
Refer to section 6.9 for standby battery selection.
