CIRCUIT DIAGRAMS
-
Full Auto Air Conditioning Circuit
8-177
COMPONENT LOCATION
Name
Air conditioning compressor lock controller
Air conditioning control unit
Air-inlet sensor
Air-therm0 sensor
Blower motor relay
Blower motor relay (HI)
Condenser fan motor relay (HI)
Condenser fan motor relay (LO)
Data link connector
Symbol
Name Symbol
H
Dual pressure switch
B
D
ELC4 AA control module
D
G
Engine control module
D
E
Engine coolant temperature sensor
I
K
Interior temperature sensor
L
H
Magnetic clutch relay
A
A
Photo sensor
F
A
Revolution sensor
C
J
Thermostat
C
20N0269
lQFO134
