CHASSIS ELECTRICAL - Wiper and Washer System
REAR WIPER AND WASHER
REMOVAL AND INSTALLATION
8-357
8
9
16FO104
Removal steps of wiper motor
Removal steps of washer tube
Rear spoiler (Refer to GROUP 23A - Aero
Parts.)
Front pillar trim (RH)
Quarter trim (RH)
1. Wiper blade
Quarter upper trim (RH)
l +
2. Wiper arm
Rear roof rail trim
1
FFr%ro GRoUP 23A
3. Spacer
Rear side trim (RH)
Liftgate lower trim (Refer to GROUP 23A-
+e
Trim.)
8. Liftgate moulding, upper
9. Washer nozzle
4. Wiper motor
10. Tube and grommet assembly
11. Washertube
Removal steps of washer tank
Rear end trim (Refer to GROUP 23A-Trim.)
5. Cap
6. Washer tank
7. Washer motor
