8-340
CHASSIS ELECTRICAL - Lighting System
FOG LIGHT SWITCH
REMOVAL AND INSTALLATION
16FO220
Removal steps
1. Knee protector
(Refer to GROUP 23A- Instrument Panel.)
**
2. Column cover lower
c*
3. Column cover upper
d
4. Meter bezel
5. Fog light switch
6. Rear window defogger switch
Front of
vehicle
SERVICE POINTS OF REMOVAL
2. REMOVAL OF COLUMN COVER LOWER / 3. COLUMN
COVER UPPER
After the screws have been removed, remove the covers,
while making sure not to break the grippers.
INSPECTION
Operate the switch to check for continuity between terminals.
1
5 3
4
ON 0
0
NOTE
(1)
(2)
GO indicates that there is continuity between the terminals.
Refer to P.8-410. Check the rear window defogger switch.
