CHASSIS ELECTRICAL
-
Wiper and Washer System
8-347
L
i
Items
Specifications
Wiper and washer switch
Rated load A
Wiper switch
LO, HI
4
INT
0.22
f
0.05
Washer switch
Max. 4
Voltage drop (at 12V and the rated load)
V
Wiper switch
0.2 or less
Washer switch
0.5 or less
Rear wiper and washer switch
Rated load A
Wiper switch
5
Washer switch
5
Voltage drop V
0.1 or less
Intermittent wiper relay
<Front (incorporated in column switch)>
Intermittent interval (min.-max.)
sec.
Variable-interval intermittent wiper
Approx. 3
-
12
Delay time in washer moving
sec.
0.6
<Rear>
Intermittent interval
sec.
8+2
SERVICE SPECIFICATIONS
Lq
Items
Specifications
Standard value
Front wiper blade park position (A)
mm (in.)
15
‘;
(6
t;)
SPECIAL
TOOL
Tool number and tool name
MB990449
Window moulding
remover
Diagnostic trouble
code check harness
Replaced by Miller tool
number
M B990449
DRB-II Scan Tool
MB991529
Application
-
Removal of liftgate moulding, upper
Checking the wiper and washer
system
-
Checking the wiper and washer
system using a voltmeter
