8-334
CHASSlS
ELECTRICAL
-
Linhtinn
Svstem
Vehicles
with
large
bumper
Vehicles
with
small
bumper
FOG LIGHT AIMING
1.
Place vehicle on a known level floor 7.6 m (25 feet) from
aiming screen or light colored wall.
2. Adjust the adjusting screw so that the top end of high
intensity area may come to the same level as the fog light
center height.
d
w
16FO490
Vertical center line
f
ahead of fog light
Height of fog
light center
hot zone
Within
151
(6.0)
Hot
zone-
mm (in.)
’
Within
600
(23.6)
Within
’
600
(23.6)
16F048E
BULB REPLACEMENT
1. Disconnect the connector.
2. Turn the bulb socket counterclockwise to pull it out.
Caution
Do not touch the surface of the headlight bulb with hands
or dirty gloves. If the surface dies become dirty, clean it
with alcohol or thinner, and let it dry thoroughly before
d
installing.
16FO508
