ENGINE ELECTRICAL
-
Charging System
8-235
2-3mm
LO79
-
.I
18 in.)
\
u
8EL006t
Soldered
A
II
7ELOOl
7EL0011
Rear bracket
e-S
Brush
ire
6EN087!
(2) Unsolder pigtail and remove old brush and spring.
(3) Install brush spring and new brush in brush holder.
(4) Insert the brush to where there is a space 2 to 3 mm
(.079
to
.I
18 in.) between the limit line and the end of the brush
holder.
(5) Solder pigtail to brush holder as shown in the illustration.
SERVICE POINT OF REASSEMBLY
2. INSTALLATION OF ROTOR ASSEMBLY
Before rotor is attached to rear bracket, insert wire through
small hole made in rear bracket to lift brush. After rotor has
To Next Page
