CHASSIS ELECTRICAL - Lighting System 8-305
TROUBLESHOOTING HINTS
L
/
L
Phenomenon
Headlights don’t come on.
But the tail lights do
illuminate.
Checking method
l Check the headlight relay. (Refer to P.8-338.)
l Check the lighting switch. (Refer to P.8-344.)
l Check the light automatic shut-OFF unit.
(Refer to P.8-339.)
The tail lights also don’t
illuminate.
The low beam at both sides doesn’t illuminate.
l Check the fusible link 0.
l Check the “LO” contacts of the dimmer
switch.
The upper beam at both The passing signal
sides doesn’t illuminate.
functions OK.
The passing signal
doesn’t function.
One headlight doesn’t illuminate.
Can’t switch from low to high beam or vice versa.
l Check the “HI” contacts of the dimmer
switch.
l Check the dimmer switch.
(Refer to P.8-344.)
l Check the bulb.
l Check the dimmer switch.
(Refer to P.8-344.)
The high beam indicator
light doesn’t illuminate.
Headlights are not
automatically shut off.
The high beam of the
headlights is normal.
Tail lights are
automatically shut off.
Tail lights are not
automatically shut off
either.
l Check dedicated fuse No. 0.
l Check the bulb.
l Check the light automatic shut-OFF unit.
(Refer to P.8-339.)
l Check the driver’s side door switch.
(Refer to GROUP 23A- Door Assembly).
l Check the light automatic shut-OFF unit.
(Refer to P.8-339.)
NOTE
For information concerning the theft-alarm system, refer to P.8-412.
