8-404
CHASSIS ELECTRICAL
-
Radio and
TaDe
Plaver
Antenna
going
down
Antenna
going
up
16FO204
16FO203
Antenna
motor
connector
’
Body
harness
side
‘/
\
;6FO198
Attachmenl
wire
Seat
back
lole
z
‘Ocktfii
g
nut
16A0332
Anten
INSPECTION OF MOTOR ANTENNA CONTROL UNIT
<VEHICLE WITH MOTOR ANTENNA>
(1)
Connect the harness connector to the motor antenna.
(Body harness)
(2) Disconnect the antenna motor connector.
(3) With the ignition switch in the ACC or ON position, operate
d
the radio switch and check the voltage between the
terminals during the period when the antenna is going up or
going down.
Antenna operating
Terminals to check
direction
Voltage
(V)
Down
l-3
10
-
13
UP
3-4
10
-
13
SERVICE POINT OF INSTALLATION
6. INSTALLATION OF REAR SEAT CUSHION
(1)
Securely fit the attachment wire of the seat cushion
under the seatback.
(2) Pass the inner seat belt buckles through the cushion.
(3) Securely fit the lock plates of the seat cushion into the
holes in the floor.
d
REPLACEMENT OF ANTENNA POLE <VEHICLE
WITH MOTOR ANTENNA>
(1) Remove the ring nut.
(2) Set the radio switch to ON. After the antenna pole has
extended, remove the antenna pole and rack cable as an
assembly.
