DOGA DPC TOUCH V2 - Page 11

User manual DPC Touch V2 DOC.60352-11/20
11
Electrical Characteristics
Input power
DC 24 V 1 A
Adaptor (provided)
AC 100-240 V ~ 50 - 60 Hz
Plug
European Union / United Kingdom / USA
Physical Characteristics
Width
202 mm / 7,952 in
Depth (with support)
39,6 mm / 1,568 in
Height
128 mm / 5,039 in
Mass excluding power
0,55 kg / 1,21 lbs
Packaging (w x d x h)
300 x 255 x 65 mm
11,81 x 10,04 x 2,56 in
Use temperature
15 - 40°C
Humidity
15 - 85% HR
User interface
Screen
7’’ LCD Touch Screen, 800x480 px
Visualization of assembly process with
graphical instructions
Inputs & Outputs 24V
12 inputs & 12 outputs
with assignable functions
Analog encoders
4 channels, 0...5V
Memory Card
Removable SD card, 8Gb
Total jobs memory
255 jobs
Total positions memory
255 jobs x 80 steps x 50 positions
per fastening step
Programming
Automatic and manual programming of a
fastening step
Position accuracy
0.09° for angular encoders
<0.5 mm for linear encoders
