The table below shows the relation between Job select signals and Job
number in binary logic.
Job
Number
Job Select
1
Job Select
2
Job Select
3
…
Job Select
8
0
0
0
0
0
0
1
1
0
0
0
0
2
0
1
0
0
0
3
1
1
0
0
0
4
0
0
1
0
0
…
255
1
1
1
1
1
NOTE: See Output’s settings for direct logic example.
