Dr.coffee Product Maintenance Manual 100
7.2 Agitator cleaning
7.2.1 Dismantling method of agitator
Step: First pull off the hose on the beverage outlet of the blender (as shown in Figure 1), then (as shown in Figure 2)
rotate the lock counterclockwise, and then (as shown in Figure 3) pull out the blender. The left and right blenders are
removed in the same way.
★ Precautions:
This item is only available for F22 models
7.2.1 Installation method of agitator
Step: First (as shown in Figure 1) flush the mixer, then (as shown in Figure 2, 3 and 4) install the mixer back into the
machine, rotate the lock clockwise to lock it, and finally plug in the hoses.
★ Precautions:
This item is only available for F22 models
1. Before reinstalling, please be sure to wipe the water from the filter sponge and the powder guide completely!
1
2
3
4
1
2
4
3
