Rev 00
Dr.coffee Product Maintenance Manual 98
7.1.2 Installation method of bubbler
Step 1: (as shown in Figure 1) Take the bubbler under the water faucet for washing and cleaning; Then dry the water in
the powder guide mouth (as shown in Figure 2);
Step 2: (as shown in Figures 1, 2 and 3) Grasp the bubbler and place it on the platform of the card holder indicated by
the red arrow;
Step 3: Then (as shown in Figure 1) put your hand on the bottom of the tray, push the bubbler upward until the buckle is
in place, and finally install the slag box back;
★ Precautions:
1. When installing the bubbler, please pay attention to that first place the bubbler on the platform of the card
holder, and then push the card holder to lock it in place!
2. The bubbler is made of metal and weighs a lot. In the process of disassembly, you can properly use your hands to
1
2
3
1
2
1
2
3
