Dr.coffee F20 - Three-Way Milk Valve Removal (F20)

Rev 00
Dr.coffee Product Maintenance Manual 84
6.2.14 Remove the three-way milk valve
Step 1: First pull out the three water pipes and wiring plugs at the position shown in Figure 1, and loosen the two screws shown
in Figure 2;
Step 2: unscrew the fixing nut of the three-way milk valve at the position shown in Figure 1, and remove the milk valve.
★ Precautions:
1. Be careful during disassembly to avoid scratching fingers!
2 1
1
2
