Instructions for Use Infinity Acute Care System - Monitoring Applications SW VG1
Device Symbols
Read accompanying documents for
specific safety information
Lower alarm limits
Attention: consult accompanying
documents
Upper alarm limits
Access to trend pages Autoset alarm limits
Access to special procedure pages Alarm monitoring is disabled
temporarily.
Access to alarm functions Alarm monitoring is disabled
permanently.
Access to the standby and privacy
modes, and access to discharging a
patient
Audible alarm tone is paused
temporarily
Access to pre-configured Views and
layouts
Audible alarm tone is turned off
permanently
Access to parameter-setup pages Change clinical password
Adult patient category Respiration value
Paediatric patient category Heart blip that flashes with each
detected pulse
