Operating Concept
Filtering the Parameter Content
You can filter the content of the displayed
parameters with the display filter button, which
appears in the following dialogue windows:
– The parameter setup window of the
Trends/Data dialogue window (see page 114);
this also includes the setup page for the mini-
trend display.
–The Sensor parameters dialogue window
where it appears to the right of the parameter
tabs.
–The Alarms dialogue window (see page 89).
You can toggle the display from unfiltered to filtered
using this filter button. When the display filter button
appears on the light green background, the filter is
enabled. This means that only the parameters that
are connected are displayed. Any parameter that is
not being actively monitored is removed from the
screen, including parameter-specific setup buttons
or tabs.
Touching the button again changes the background
to dark green and disables the display filter. All
parameters, including associated setup buttons or
tabs, are displayed.
Auto vs. Manual Display Modes
The user interface has two display modes: Auto
View and Manual View.
Auto View Mode
The Auto View mode is a plug-and-play concept
where the content of the main screen depends on
the connected parameter signals. For example, as
soon as you connect an SpO
2 MCable, the
associated parameters become available for
display. When you disconnect the MCable, the
parameters are removed from the screen
automatically.
Manual View Mode
In the manual mode, you can select parameters for
display even if they are not yet connected. In this
mode, the parameter selection list in the Auto view
setup page (see page 53) contains all parameters.
The parameters that are not connected appear
grey in the parameter selection list. In addition, the
display filter button is disabled.
To select the display mode
1 Select System setup... from the main-menu
bar.
2 Select the Screen setup tab.
3 Select the Auto view tab located along the right
side of the System setup dialogue.
4 Select the Auto or Manual button next to the
Display mode menu selection.
