Dräger Infinity Acute Care System - Cockpit Screen in Split Screen Mode

Instructions for Use Infinity Acute Care System - Monitoring Applications SW VG1 49
Operating Concept
Cockpit Screen in Split-Screen Mode
When the split-screen mode is enabled (see
page 278), the monitoring area of the Cockpit is
reduced to accommodate a display panel. The
larger right side continues to display the real-time
parameters while the left side displays either a
trend table, vent loops, ECG show all, ECG/Vent or
ECG/ST, or ST parameters (see page 277).
The following diagram shows how the screen is
divided up in the split-screen mode.
A Header Bar
B The main screen menu bar
C The auto-view setup toolbar (if enabled)
D The monitoring area with real-time vital signs
E The split-screen panel (content depends on
user selection)
012
A
B
C
D
E
