Operating Concept
40
Instructions for Use Infinity Acute Care System - Monitoring Applications SW VG1
Secondary Display
To extend the display capabilities of a Cockpit, you
can connect a secondary display to the DVI
connector of the Cockpit using one of two LCOM
cable types which have been qualified by Dräger:
The secondary display duplicates the content of the
Cockpit screen. It does not produce any audible
alarm signals and does not support any user
interaction. A secondary display has to meet
certain technical specifications (see page 365).
Dräger has qualified the ViewSonic, 19-inch
(48.3 cm) widescreen high-resolution display. The
ViewSonic has a display resolution of 1680 x 1050
pixels.
User Interface
The following sections describe the user interface
of the Cockpit when it is connected to an M540.
The screen of a monitoring Cockpit is divided into
the following main areas:
A Header Bar
B Main-Menu Bar
C Auto-view toolbar (if enabled)
D Monitoring Area
For a more detailed overview of general user
interface components of the IACS, refer to the
Infinity Acute Care System - Medical Cockpit
Instructions for Use.
Cable type Length Part number
DVI to DVI 0.91 m (3 ft) CTLDVI-DL-MM3
1.52 m (5 ft) CTLDVI-DL-MM5
3.04 m (10 ft) CTLDVI-DL-MM10
4.75 m (15 ft) CTLDVI-DL-MM15
DVI to VGA 0.91 m (3 ft) CTLDVI-HD-MM3
1.52 m (5 ft) CTLDVI-HD-MM5
3.04 m (10 ft) CTLDVI-HD-MM10
4.75 m (15 ft) CTLDVI-HD-MM15
008
