Dräger Infinity Acute Care System - Supported Parameters

Instructions for Use Infinity Acute Care System - Monitoring Applications SW VG1 261
External Device - Ventilator
Supported Parameters
The following table lists all parameters supported
with the device connectivity option. However, the
ventilator in use determines which of these
parameters are available to the Cockpit and the
network. You can review the settings for all
ventilator parameters at the ICS (they are not
displayed at the Cockpit). The ventilators provide
the range and resolution for all parameters.
Parameter Label Unit
End-tidal CO
2 etCO2 mmHg, kPa, %
Minimum airway pressure
(1), (2)
PAW min. mbar
Occlusion pressure
(1)
Occlusion Press mbar
Trapped volume
(1)
Trapped VOL ml
Gas temperature
(1)
AW-Temp
o
C
Dead space
(2)
TVd aw ml
Peak inspiratory pressure
(2)
PIP mbar or cmH2O
Mean airway pressure
((2)
MAP mbar or cmH2O
Peak-end expiratory airway pressure
(2)
PEEP mbar or cmH2O
Tidal volume, expiratory
(2)
TVe ml or L
Minute volume, expired
(2)
MVe L/min
Respiratory rate
(2)
RRv min.
Inspired O
2
(2)
inO2 (Cockpit label)
iO
2* (network label)
%
Relative dead space
(2)
TVd aw% %
Minute volume, expired, spontaneous
(2)
MV e s L/min
Respiratory rate, spontaneous
(2)
RRs br/m
Pause pressure
(2)
Pause cmH2O
inspiratory:expiratory ratio
(2)
I:E No units
inspiratory:expiratory ratio (inspiratory
component)
(2)
I:E I-Part No units
inspiratory:expiratory ratio (expiratory
component)
(2)
I:E E-Part No units
Dynamic compliance
(2)
Cdyn L/bar
Resistance
(2)
Raw mbar/L/s
Tidal volume setting, inspired
(2)
TVi set ml or L
CO
2 production
(2)
VCO2 ml/min
(1)
This parameter is only available on the Infinity network. It is not available at the Cockpit.
(2) This parameter is also displayed in the Show All page (see page 264).
