Alarms
76
Instructions for Use Infinity Acute Care System - Monitoring Applications SW VG1
Visual Alarm Signals
Each alarm priority has its own distinct visual alarm
signals. When the M540 is docked on the M500,
only the Cockpit provides audible alarm signals.
However, visual alarm signals (see page 76)
appear on the Cockpit and the M540.
The alarm message in the header bar is the only
visual alarm signal if an alarming parameter is not
included in the current screen view or the alarm bar
is disabled. For more information on alarm
messages, see page 78.
Alarm Priority Parameter Box Alarm Message Field
(1)
in Header Bar
Alarm Bar
(if enabled, see
page 287)
High (life-threatening)
(for example, asystole,
ventricular fibrillation)
Flashing red background Red background Flashing red
Medium (serious)
(for example, alarm
limit violations)
Flashing yellow
background
Yellow background Flashing yellow
Low (advisory)
(for example,
disconnected lead)
Solid cyan background Cyan background No visual signal
(1)
Note: Cockpit alarm messages are designed to be legible from a distance of 1 metre (3.3 feet) to 2
metres (6.6 feet). M540 alarm messages are legible at arm’s length.
