DURKOPP ADLER 745-34-2 Installation Instructions

–
Loosen screws 5 and 6.
–
Place the knife holder 4 with the center knife 3 to the left against
the stationary k nife in the throat plate.
The center knife must abut in parallel position and with slight
pressure.
–
Tighten screws 5 and 6.
–
Make a cutting test.
–
For correction place the center knife in parallel position by slightly
turning the knife drive shaft 7 to the left.
43
3
43
65
87
