4.4 Distance between the feeding clamps and the sole of the folder
Standard checking
Between the outer edges 1 of the folder sole and the inner edges 2 of
the feeding clamps there must be a certain distance. When processing
medium-weight clothing fabrics the distance should amount to approx.
1.0to1.5mm.
The distance is required to guarantee equal piping strips on both sides
and an unhindered feed of the workpiece.
Caution: Danger of injury !
Check and adjust the feeding clamps with utmost caution when the
sewing unit is switched on.
–
Uncouple the pneumatic coupling for the locking sheets.
–
Switch into the pocket programs with function key F1.
–
Select the program for quick clamp adjustment with the cursor
keys “ï”or“ð”.
Attention: Danger of breakage !
Select the corresponding clamp position according to the folder.
–
Select the corresponding symbol.
–
Press key OK.
The clamp position is taken over.
–
Press key RST.
The clamp position is taken over.
–
Select key F2 (pocket sequence).
–
Start the step-by-step mode.
64
21
43
