Setting the drive
Service instructions 967 - 00.0 - 12/2014
29
6.2.2 Adjusting the reference position of the handwheel
Correct setting
The reference position is 105° on the handwheel scale (2).
Setting steps
1. Select parameter setting mode in the field OP1000 (1) and set the param-
eter t 08 10 ( DAC basic/classic Service instructions).
2. Manually turn the handwheel (2) at least one revolution and turn it to
105° on the scale ( page 20).
3. Acknowledge the set position by pressing the OK button.
4. To exit parameter setting mode, press the Esc key.
5. Switch the machine on and off.
