Adjusting the thread cut-off
80
Service instructions 967 - 00.0 - 12/2014
14.5 Adjusting the cutting pressure of the knife
Correct setting
The cutting pressure should be as low as possible, consistent with cutting
the thread reliably.
Faults caused by an incorrect setting
• Very rapid wear of the knife if the pressure is set too high
Cover
• Tilt the upper section ( page 10).
Figure 55: Setting the cutting pressure of the knife
Setting steps
1. Put the handwheel into the 270° position page 20.
2. Swing out the movable knife (2).
3. Adjust the cutting pressure, using the regulating screw (1).
4. Check the knife for correct operation and adjust it if necessary.
(1) - Regulating screw (2) - Movable knife
ཱ
