Adjusting the thread system
68
Service instructions 967 - 00.0 - 12/2014
13.2 Setting the winder
The winder is driven by its own electric motor. After it has wound the bob-
bin it switches off automatically.
Correct setting – part 1
The regulating screw (2) is tightened so that the arms of the winder
lever (1) are approximately parallel.
The winder is switched off mechanically when the winder pulley (5) reach-
es a distance of L = 8 mm from the internal diameter of the bobbin (4) –
the roller is approx. 1 mm below the outer diameter of the bobbin.
When the winder has switched off and is locked in the home position:
The winder pulley (5) is located at a distance of L=14 mm from the
internal diameter of the bobbin.
Cover
• Thread tensioning plate ( page 13).
WARNING
Risk of injury
Switch the machine off before checking or adjusting the winder
on the machine.
