Adjusting the thread cut-off
76
Service instructions 967 - 00.0 - 12/2014
5. Move the control cam (3) to a distance of 1 mm from the lever (2), man-
ually press the lever down and manually rotate the control cam until the
pulley (7) engages in the setting gully (6).
6. Tighten the screws (4).
14.2 Basic setting of the thread cutter
Correct setting
When the stop lever (6) is touching the baseplate (5) of the machine:
The distance between the control cam (4) and the roller (1) must be
0.1 to 0.2 mm.
The piston of the pneumatic cylinder must be 0.5 to 1 mm from the
base of the cylinder (it must not be touching it).
Cover
• Upper right cover ( page 11).
• Tilt the upper section ( page 10).
