Setting the feed dog
44
Service instructions 967 - 00.0 - 12/2014
Setting steps
1. Place the feed dog at top dead center.
2. Loosen the setscrews (2).
3. Push the feed dog carrier (1) upwards so that the upper edge of the
feed dog protrudes 1.3 mm above the throat plate.
4. Tighten the setscrews (2).
8.2.3 Adjusting the stroke movement
Sequence
First check the following setting:
• feed dog height ( page 43)
Correct setting
The upper edge of the feed dog must be the same height when the feed
dog is at front dead center (handwheel position 90°) as when it is at rear
dead center (handwheel position 270°).
At 90° the feed dog is moving upwards; at 270° it is moving downwards.
Cover
• Take off the upper right cover ( page 11)
WARNING
Risk of injury!
Crushing injuries from moving parts.
Switch the sewing machine off before you check
and set the stroke movement of the feed dog.
