DURKOPP ADLER 967 Service Instructions

Position of the hook and needle
Service instructions 967 - 00.0 - 12/2014
53
10.3 Setting the loop stroke position
Correct setting
When the stitch length is set to 0 and the machine is stopped at position 1:
 The tip of the hook (3) is central to the axis of the needle.
Figure 36: Setting the loop stroke position
Setting steps
1. Set the stitch length to 0.
2. Locking the machine in place ( page 19).
3. Loosen the screw (1).
4. Loosen the screws (2).
5. Turn the tip of the hook (3) so that it is central to the axis of the needle.
6. Tighten the screws (2).
7. Tighten the screw (1).
(1) - Screw
(2) - Screws
(3) - Tip of the hook
(4) - Groove
཰
ཱ
ི
ཱི
