Adjusting the sewing foot feed
Service instructions 967 - 00.0 - 12/2014
59
11 Adjusting the sewing foot feed
11.1 Adjusting the zero stroke of the feet, tension force of the
torsion spring
In order to adjust the sewing foot stroke mechanism ( page 61) the zero
stroke of the sewing feet must be precisely adjusted, with the upper ma-
chine cover removed. This is the case when the connecting rods (1) are in
a line.
Correct setting
When the connecting rods (1) are in a line.
The ball-ended pin (7) is touching the stop screw (9).
The torsion spring is twisted 15° to 20°.
Cover
• Arm cover ( page 11)
WARNING
Risk of injury
Switch the machine off before checking or adjusting the
position of the sewing foot feed on the machine.
