Setting the feed dog
Service instructions 967 - 00.0 - 12/2014
39
8 Setting the feed dog
The position and the movement of the feed dog and needle bar have to
be coordinated such that the needle pierces exactly in the center of the
needle hole of the feed dog.
Sequence
First check the following setting:
• Needle bar linkage ( page 47)
8.1 Setting the feed dog position
Correct setting
When the stitch length is set to 0 and the needle is at bottom dead center:
 The center of the feed dog opening (2) is inline with the axis of the
needle.
Cover
• Tilt the upper section ( page 10).
WARNING
Risk of injury
Switch the machine off before checking or adjusting the
position of the feed dog on the machine.
