Aligning the needle bar linkage
Service instructions 967 - 00.0 - 12/2014
47
9 Aligning the needle bar linkage
The precondition for performing adjustment is that the axial movement
of pins and shafts running in plain bearings is correctly restricted
( page 18).
9.1 Moving the needle bar linkage laterally
Correct setting
When the stitch length is set to 0 and the value 90° is set on the handwheel
scale:
Needle bar (4), sewing foot bar (5) and presser foot bar (6) are all in
a line.
Cover
• Upper covers ( page 11).
• Front cover (
page 12).
WARNING
Risk of injury
Switch the machine off before checking or adjusting the
alignment of the needle bar on the machine.
