Working basis
10
Service Instructions 967 - 02.0 - 12/2015
3.3 Removing the covers
In many types of setting work, you will have to remove the machine covers
first in order to access the components.
Described here is how to remove the individual covers and how to refit
t
hem. Just the cover that needs to be removed is then specified in the text
for that particular type of setting work.
3.3.1 Access to the machine bottom section
In order to access the components at the machine bottom section, you
must first swivel up the machine head.
Fig. 1: Tilting and erecting the machine head
Tilting the machine head
1. Tilt the machine head as far as it will go.
Erecting the machine head
1. Erect the machine head.
WARNING
Risk of injury!
Crushing injuries from moving parts.
Switch the machine off before you remove the
cove
rs or refit them.
